Leica M10 monochrom camera
Leica M10 monochrom camera
8 840 EUR

Leica M10 monochrom camera

Leica M10 monochrom camera
Leica M10 monochrom camera
Leica M10 monochrom camera
Leica M10 monochrom camera
Leica M10 monochrom camera
ISO 100.000

ISO setting dial

Built as an analogue M

B-W 40 MP sensor
Available for order
8 840 EUR
We recommend the following product(s) as accessories
Details

Discover more in black and white











The Leica M10 Monochrom opens the door to a new dimension of black-and-white photography. Equipped with a newly developed image sensor, the camera delivers an extremely high-quality rendition with breathtaking detail resolution.



The absence of a color filter array and exceedingly high sensor resolution of 40 megapixels result in an unprecedented depiction of even the finest details, along with an exceptionally natural-looking sharpness.



The new M10 Monochrom and its high-resolution sensor represent an uncompromising commitment to classic black-and-white photography, which has now been elevated to an entirely new level of image quality. No other camera consolidates the most fundamental of all photographic practices — the composition of images using only contrast and light — with a recording quality that can only be achieved with state-of-the-art methods of engineering and construction.







Improved detail rendition for greater image quality
















The Leica M10 Monochrom occupies a special place within the M-System: its newly developed image sensor is designed exclusively for grayscale recordings and offers exceptional fine-detail rendition thanks to its exceedingly high, 40-megapixel resolution.



The fact that no color filter arrays are required means that there are fewer glass and filter layers to impede the transmission of light or cause deflections.



This is especially advantageous in a traditional rangefinder camera, and results in decreased, finer-grained image noise. In addition, the sensor’s enormous sensitivity range of ISO 160 to ISO 100,000 enables recordings with an extremely broad dynamic range – yielding images whose areas of shadow and illumination are clearly defined, particularly when shooting in uneven, high-contrast light.










Understated and discreet for low-profile shooting







The Leica M10 Monochrom is the epitome of discretion — which is why we chose to omit the familiar, and potentially eye-catching, red dot. In a similar vein, the “Leica M10 Monochrom” inscription on the top plate is considerably more subtle. The strict omission of any color-inlaid engravings further emphasizes the camera’s monochrome character.



The camera shutter is barely audible, enabling recordings in situations in which other cameras would be too obtrusive. Thanks to its understated appearance, the M10 Monochrom allows photographers to blend into the crowd and capture their subjects without drawing attention.







A reliable companion - Made in Germany







The Leica M10 Monochrom is hand-crafted by accomplished specialists using superior-quality materials and elaborate methods of engineering.



For example, the camera’s top and base plates are neither stamped nor molded, but milled from solid blocks of brass.



Due to its robust construction, the Leica M10 Monochrom can weather even the toughest external conditions.



‘Made in Germany’ guarantees the utmost quality, reliability and durability, ensuring long-term value and functionality. After all, a Leica is not just a camera, but represents a worthwhile, life-long investment.







Utilizing the full scope of the camera’s capability



















With its high-resolution image sensor and faithful detail rendition, the Leica M10 Monochrom has significantly raised the bar in terms of camera quality and performance. This, in turn, means that only equally high-capacity lenses will be able to utilize all of the camera’s performance reserves.



Leica M-Lenses — globally recognized as the world’s best full-frame lenses — are the perfect match for the Leica M10 Monochrom, giving rise to an exceptionally high-performance combination.






Details:


































































Camera type
Compact digital view and rangefinder system camera with a dedicated black-and-white image sensor
Lens attachment
Leica M bayonet with additional sensor for 6-bit coding
Lens system
Leica M lenses, Leica R lenses with an optional adapter (available accessory)
Sensor
B/W CMOS chip, active area approx. 24x36 mm, without color and low-pass filter
Resolution
DNG™: 7864 x 5200 pixels (40,89 MP),

JPEG: 7840 x 5184 pixels (40,64 MP), 5472 x 3648 pixels (20 MP), 2976 x 1984 pixels (6MP)
Data formats
DNG™ (raw data, compressed loss-free), JPEG
File size
DNG™: 40-60 MB, JPEG (40MP)10-20 MB: Depending on resolution and picture content
Buffer memory
2GB / 10 pictures in series
Storage media
SD cards up to 2GB/SDHC cards up to 32GB/SDXC cards up to 2TB
Menu languages
German, English, French, Spanish, Italian, Portuguese, Japanese, Traditional Chinese, Simplified Chinese, Russian, Korean
Exposure metering
Exposure metering through the lens (TTL), with working aperture
Metering method
Light reflected by the blades of the 1 shutter curtain onto measuring cell
Metering range
At room temperature and normal humidity for ISO 200, at aperture 1.0 EV-2 to EV19 at aperture 32. Flashing of the left triangular LED in the viewfinder indicates values below the metering range
Sensitivity range
ISO 160 to ISO 100.000, adjustable in 1/3 ISO increments from ISO 160, choice of automatic control or manual setting
Exposure modes
Choice of automatic shutter speed control with manual aperture preselection - aperture priority A, or manual shutter speed and aperture setting





































Flash exposure control
Flash unit attachment
Via accessory shoe with central and control contacts
Synchronisation
Optionally triggered at the 1st or 2nd shutter curtain
Flash sync time
1/180 s; slower shutter speeds can be used, if working below sync speed: Automatic changeover to TTL linear flash mode with HSS-compatible Leica system fl ash units
Flash exposure metering
Using centre-weighted TTL pre-flash metering with Leica flash units (SF40, SF64, SF26), or flash units compatible with the system with SCA3502 M5 adapter
Flash measurement cell
2 silicon photo diodes with collection lens on the camera base
Flash exposure compensation
±3EV in1⁄3EV increments
Displays in flash mode (in viewfinder only)
Using flash symbol LED









































Viewfinder
Construction principle
Large, bright line frame viewfinder with automatic parallax compensation
Eye piece
Calibrated to -0.5 dpt.; corrective lenses from -3 to +3 diopter available
Image field limiter
By activating two bright lines each: For 35 and 135mm, or for 28 and 90mm, or for 50 and 75mm; automatic switching when lens is attached.
Parallax compensation
The horizontal and vertical difference between the viewfinder and the lens is automatically compensated according to the relevant distance setting, i.e. the viewfinder bright-line automatically aligns with the subject detail recorded by the lens
Matching viewfinder and actual image
At a range setting of 2m, the bright-line frame size corresponds exactly to the sensor size of approx. 23.9 x 35.8mm; at infinity setting, depending on the focal length, approx. 7.3% (28mm) to 18% (135mm) more is recorded by the sensor than indicated by the corresponding bright line frame and slightly less for shorter distance settings than 2m
Magnification
(For all lenses) 0.73 x
Long-base rangefinder
Split or superimposed image range finder shown as a bright field in the centre of the viewfinder image
Effective metering base
50.6mm (mechanical measurement basis 69.31mm x viewfinder magnification 0.73x)

















Displays
In the viewfinder
Four-digit digital display with exposure alerts above and below
On back
3" colour TFT LCD monitor with 16 million colours and 1,036,800 pixels, approx. 100 % image field, glass cover of extremely

hard, scratch-resistant Gorilla® glass, colour space: sRGB, for Live-View and review mode, displays









Shutter and shutter release
Info
Article number
20050
Manufacturer
Leica
Power supply
Leica BP-SCL5 lítium- ion akku, 7,4 V, 1100 mAh
Screen
3 coll
Warranty
2 years manufacturer's warranty
Dimensions
139x38.5x80mm
Working / storage temperature
0–40 °C
Lens compatibility
Leica M bayonet
Lens system
Leica M, Leica R with adapter
Body
magnesium
Internal flash shoe
Yes
ISO
ISO 100 - ISO 100000
Self-timer
2 s, 12 s
File format
DNG, JPEG
Built-in flash
none
Flash sync
optional first or second shutter, flash sync shutter speed: 1 / 180s
Category
digital, rangefinder camera
Photo resolution
DNG: 24MP; JPEG: 24MP, 12MP, 6MP
Finder
optional Leica Visoflex
Battery
Leica BP-SCL5
Wi-Fi
IEEE 802.11b/g/n standard (standard Wifi protokoll), WPA™/ WPA2™
Resolution
DNG™: 7864 x 5200 pixel (40,89 MP), JPEG: 7840 x 5184 pixel (40,64 MP), 5472 x 3648 pixel (20 MP), 2976 x 1984 pixel (6MP)
Weight (g)
660
Touchscreen
none
Aspect ratio
n.a.
Aperture preselection
n.a.
Sensor
40 MP CMOS 24 x 36 mm
In the box
charger, 12v cable, battery, neck strap, bayonet cap, cover for accessory shoe
Shutter speed preselection
n.a.
Color
black
Material
magnesium frame, synthetic leatherette, copper
Manufacturer's warranty
2 év
Objektív
Leica M, Leica R adapterrel
Article No.
20050
Videó
